Ferrous & Steels
Alloy Irons
- Grades
- 13
- Elements tabulated
- 11
Overview
High-alloy irons and Ni-Resist type castings offering corrosion and heat resistance in chemical, pump and process equipment.
IMS handles alloy irons as both prime material and as arisings recovered from industrial processing. Material is sorted and segregated by grade, so it returns to the melt as a known specification rather than a mixed stream.
Properties
- Heat Resistant
- Corrosion Resistant
- Acid Resistant
Applications
- Chemical and Food Industry
- Aero Engine Parts
Chemical composition
13 grades · percentage by weight
| Grade | Ni | Cr | Cu | Fe | Al | Ti | Mn | Si | C | Zn | Others |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Nihard Type 1 | 4.5 | 2 | – | BAL | – | – | 0.5 | 0.6 | 3 | – | – |
| Nihard Type 4 | 6 | 9 | – | BAL | – | – | 1.3 | – | 3 | – | – |
| Niresist 1 L-Ni Cu Cr 15 6 2 | 15.5 | 2.2 | 6.5 | BAL | – | – | 1 | 2 | 3.0* | – | – |
| Niresist 2 L-Ni Cr 20 2 | 20 | 2.2 | 0.5* | BAL | – | – | 1 | 2 | 3.0* | – | – |
| Nicrosilal S-Ni Si Cr 20 5 2 | 20 | 1.75 | 0.5* | BAL | – | – | 1 | 5 | 3.0* | – | – |
| Nicrosilal L-Ni Si Cr 20 5 3 | 20 | 3.2 | 0.5* | BAL | – | – | 1 | 5 | 2.5* | – | – |
| Niresist 3 L-Ni Cr 30 3 | 30 | 3 | 0.5* | BAL | – | – | 1 | 1.5 | 2.5* | – | – |
| Niresist SG D2 S-Ni Cr 20 2 | 20 | 1.75 | 0.5* | BAL | – | – | 1 | 2.2 | 3.0* | – | – |
| Niresist SG D2C S-Ni 22 | 22 | 0.5* | 0.5* | BAL | – | – | 2 | 2 | 3.0* | – | – |
| L-Ni Mn 13 7 | 13 | 0.2* | 0.5* | BAL | – | – | 6.5 | 2.2 | 3.0* | – | – |
| Niresist 4 L-Ni Si Cr 30 5 5 | 30.5 | 5 | 0.5* | BAL | – | – | 1 | 5.5 | 2.5* | – | – |
| Niresist 5 L-Ni 35 | 35 | 0.2 | 0.5* | BAL | – | – | 1 | 1.5 | 2.4* | – | – |
| Niresist D-2M s-Ni Mn 23 4 | 23 | 0.2* | 0.5* | BAL | – | – | 4.25 | 2 | 2.6* | – | – |
Select grades to compare them side by side, or save them to a shortlist.
* indicates maximum. The figures shown are nominal compositions of the various alloys. Values are reproduced from IMS technical data and are provided for identification purposes; confirm the specification against your own requirement before ordering.
Scroll the table sideways to see all elements, or switch to cards above.
